Constructing A Chicken Run: Pvc Pipe Innovation

PVC pipes can be used to build a chicken run that is lightweight, inexpensive, and easy to assemble. While PVC pipes may not offer protection against predators, they can be used to create a structure that keeps birds away. The process involves cutting the pipes to the desired length, connecting them with joints and connectors, and attaching protective netting or fencing around the frame. Perches can be added using lumber and wire ties, ensuring a minimum width of 2 inches for flat-footed chickens. The structure can be made portable, but it may still be challenging to move due to weight. PVC pipes are affordable and easy to work with, but some may prefer wood for aesthetic and environmental reasons.

Advantages of using PVC pipes

There are several advantages to using PVC pipes to build a chicken run. Firstly, PVC pipes are lightweight and affordable, making them a cost-effective option for constructing a chicken run. They are also easy to assemble, as no welding skills are required. This ease of assembly can save time and effort in the building process.

Another benefit of PVC pipes is their durability. With proper treatment, PVC pipes can last for a decade or more, even in harsh weather conditions. For example, in regions with intense sun exposure, painting the PVC pipes can help them last up to 15 years without significant deterioration. Similarly, in wet climates, PVC pipes can be a better alternative to wood, as they are not susceptible to rot.

PVC pipes also offer flexibility in design. They can be easily connected using various joints and connectors, allowing for the creation of different shapes and structures. This adaptability makes them suitable for building chicken runs of varying sizes and configurations.

Additionally, PVC pipes are smooth and slide easily on surfaces such as grass. This feature can be advantageous when creating a portable chicken run, as it facilitates movement and reduces friction with the ground.

Overall, the advantages of using PVC pipes for a chicken run include their affordability, ease of assembly, durability, design flexibility, and smooth surface, making them a versatile and practical choice for constructing a functional and long-lasting chicken enclosure.

Cutting and assembling the frame

To build the frame for your chicken run, you'll need to cut and assemble PVC pipes and connectors. Here's a step-by-step guide:

Cutting the PVC Pipes:

• Decide on the dimensions of your chicken run and choose a suitable tarp or netting to cover it.
• Cut the PVC pipes to fit the size of your tarp. For example, if you're using a 5 1/2-by-7 1/2 foot tarp, cut your pipes to 7 1/2 feet in length.
• Cut 22 pieces of 3/4-inch PVC pipe to 20 inches in length for the base.
• Cut 12 pieces of the same pipe to 20 inches for the top and door.
• For the vertical base supports, cut 14 pieces to 22 inches in length.
• For the first cross support, cut two pieces to 1 3/4 inches and two pieces to 17 1/2 inches.
• Smooth any sharp edges to prevent injury to yourself or your chickens.

Assembling the Frame:

• Connect the pipes together with the appropriate connectors and joints.
• Assemble the base first, using the 20-inch pipes, and apply cement to secure them in place.
• Attach the vertical base supports (22-inch pieces) to the base.
• Assemble the top using the eight 20-inch pieces.
• Attach the cross supports (1 3/4-inch and 17 1/2-inch pieces) to form a stable frame.
• You can now attach the tarp or netting to the frame using zip ties or wire ties.

Remember that PVC pipe is easy to work with and can be assembled without glue or tools. The frame should be lightweight yet sturdy enough to support the tarp or netting.

Attaching the fencing

When attaching the fencing to your PVC chicken run, it's important to consider the type of fencing material you will be using. Chicken wire or wire mesh fencing provides sturdiness and protection from predators such as hawks, but it should not be used on the ground as it can be uncomfortable for the chickens. For the base, consider using a tarp or protective netting, which allows chickens to scratch and peck at the grass.

First, attach one end of your chosen fencing material to a vertical bar on the PVC frame. You can use zip ties or wire ties to secure the fencing to the frame. Roll the fencing around the frame, attaching it to each vertical PVC pipe as you go. When you reach the first vertical bar again, attach the fencing and cut off any leftover material with scissors or wire cutters.

Repeat this process for the top and bottom horizontal bars of the frame, ensuring that the fencing is securely attached and there are no gaps. If you are using a tarp, cut it to fit the size of your frame, and consider using zip ties or wire ties at regular intervals to hold it in place.

It is recommended to have two people working on this part of the build, as it can be tricky to manage the fencing and ties simultaneously. Additionally, consider the height of your chicken run and adjust the fencing accordingly to provide sufficient headroom for your chickens.

Adding a door

When creating a door for your chicken coop, you will need to cut a 3-by-3-foot hole in the side of the coop. Attach hinges and a lock to the door to restrict access. Place the hinges 2 inches from each edge of the door along the top and screw one side into the door.

For a door on the chicken run, you will need to cut an opening in the fencing and frame it with wood. You can use 1" x 3" boards or ripped 2x4s, which will give you a piece that is 1-1/2" x 1-3/4". Make sure to cover any sharp edges with wood and screw the boards together, with the screws going through the openings in the wire.

When creating the door itself, you can use 2x4s or 2x3s for the frame. You may also want to add a horizontal brace in the middle to attach latch hardware. Two hinges should be sufficient for support, but you can add a third for extra stability if desired.

Finally, add a gate lock to your door, and you're finished! This will ensure your chickens are safely locked up at night and that you can easily access the run to deliver treats or clean.

Disadvantages of using PVC pipes

While PVC pipes are a popular choice for a variety of applications, from sewage systems to agricultural irrigation, they do come with certain drawbacks. Here are some disadvantages to consider when using PVC pipes, especially for building a chicken run:

Temperature Sensitivity: PVC pipes are sensitive to temperature changes. At higher temperatures, the strength of PVC pipes decreases, making them less suitable for applications where they will be exposed to extreme heat. Conversely, like most pipes, PVC pipes can also break if they freeze.

Bulkiness: Plastic pipes tend to be bulkier than metal pipes, which can limit their use in confined spaces. This bulkiness may be a consideration when constructing a chicken run, depending on the available space and the desired size of the run.

Warping: Some types of plastic used in PVC pipes can warp when exposed to high heat. This warping could potentially affect the structural integrity of the chicken run and may create openings that predators could exploit.

Health Concerns: Plastic pipes lack the inherent antimicrobial properties of copper pipes. This may be a concern for homeowners, particularly if the pipes are used for water supply or in areas where hygiene is critical.

Strength: While PVC pipes are generally durable, their strength can be lower than that of metal pipes. In a chicken run, this could be a factor if the structure needs to support significant weight, such as a heavy roof or additional security measures.
